SHACL 1.2 Node Expressions

This document describes Shapes Constraint Language (SHACL) Node Expressions.

This specification is published by the Data Shapes Working Group .

Introduction

Node expressions

Terminology

Basic RDF Terminology

This document uses the terms RDF graph, RDF triple, IRI, literal, blank node, node of an RDF graph, datatype, RDF term, and term equality, and subject, predicate, and object of RDF triples as defined in RDF 1.2 Concepts and Abstract Syntax [[!rdf12-concepts]].

Basic SHACL Terminology

This document uses the terms focus node, value, value node, constraint, constraint component, parameter, mandatory parameter, optional parameter, parameter value, shape, node shape, property shape, SHACL property path, SPARQL property path, data graph, shapes graph, target, validator, validation result, node expression, node expression function, function name, output nodes, focus graph, evaluation, evaluation failure, conform, conformance check, failure, SHACL instance, SHACL subclass, SHACL type, SHACL list, members, well-formed, deep copy, as defined in the SHACL 1.2 Core specification [[!shacl12-core]].

Document Conventions

Some examples in this document use Turtle [[rdf12-turtle]]. The reader is expected to be familiar with SHACL [[shacl12-core]] and SPARQL [[sparql12-query]].

Within this document, the following namespace prefix bindings are used:

Prefix	Namespace
`rdf:`	`http://www.w3.org/1999/02/22-rdf-syntax-ns#`
`rdfs:`	`http://www.w3.org/2000/01/rdf-schema#`
`sh:`	`http://www.w3.org/ns/shacl#`
`shnex:`	`http://www.w3.org/ns/shnex#`
`skos:`	`http://www.w3.org/2004/02/skos/core#`
`sparql:`	`http://www.w3.org/ns/sparql#`
`xsd:`	`http://www.w3.org/2001/XMLSchema#`
`ex:`	`http://example.com/ns#`

Grey boxes such as this include syntax rules that apply to the shapes graph.

true denotes the RDF term "true"^^xsd:boolean . false denotes the RDF term "false"^^xsd:boolean .

TODO

Getting started with Node Expressions

This section is informative.

A SHACL shapes graph can declare node expressions as values of various properties where dynamic computation is useful, such as sh:targetNode, sh:values and sh:deactivated. A node expression is represented by an RDF node and can be evaluated to produce a list of output nodes. For example, when used at sh:targetNode, a node expression produces the list of target nodes of a shape. When used at sh:values, a node expression produces the derived values for the property specified by sh:path.

The following example contains a node expression that states that the target nodes of the shape ex:EstonianCompanyShape are the instances of ex:Company where the ex:headQuarterCountry is ex:Estonia.

The following diagram illustrates how this node expression is interpreted, from a logical point of view. During validation, a SHACL processor will determine the target nodes of the shape by evaluating the filterShape expression. However, the filterShape expression first evaluates its input expression, which is specified via sh:nodes and is an instancesOf expression. This will produce all instances of the given class, ex:Company. The shnex:filterShape is then applied to all of these instances, to keep only the companies that conform to the provided shape, by having their headquarters in Estonia.

Illustration of the data flow between node expressions

The scenario above can also be expressed using SPARQL select expressions. For performance reasons, for example, specific implementations of SHACL node expressions might internally convert node expressions such as the shnex:filterShape above to SPARQL.

The next example uses a node expression to compute the values of the property ex:employeeCount as the number of values of the property ex:employee at each instance of ex:Company.

Illustration of the data flow between node expressions computing the employee count

One difference between this example and the previous examples about sh:targetNode is that these node expressions are evaluated against a given focus node. This means that when a data visualization needs to render an instance of ex:Company, the currently displayed company is the focus node, for which the number of employees will be fetched.

Clarify when these derived properties can be used (e.g. in sh:path expressions but not as triples elsewhere)

Node Expression Syntax

This section introduces the general syntax of SHACL node expressions.

The term node expression function refers to the kind or type of a node expression. For example, sh:FilterShapeExpression is a node expression function, while a specific instance of this function in the graph is the node expression itself.

The most basic node expression functions are constant node expressions, which are either literals or IRIs, and simply evaluate to these constants. All other node expressions are represented by blank nodes, and come in the following two variations:

A named parameter function is represented by a blank node that is the subject of one or more triples, including the key parameter of the node expression function.
A list parameter function is comparable to a traditional function in SPARQL, for example, and is represented by a blank node that is the subject of a single triple with a SHACL list as its object.

Constant Node Expressions

The node expression functions in this section are called constant node expressions. They were introduced in the SHACL Core specification and are repeated here to keep this document self-contained.

IRI Expressions

A node expression that is an IRI is called an IRI expression with the function name sh:IRIExpression.

A node in an RDF graph is a well-formed IRI expression if it is an IRI.

EVALUATION OF IRI EXPRESSIONS

The output nodes of an IRI expression are the list consisting of exactly the node expression itself:

evalExpr(expr, focusGraph, focusNode, scope) -> [expr]

Literal Expressions

A node expression that is a literal is called a literal expression with the function name sh:LiteralExpression.

A node in an RDF graph is a well-formed literal expression if it is a literal.

EVALUATION OF LITERAL EXPRESSIONS

The output nodes of a literal expression are the list consisting of exactly the node expression itself:

evalExpr(expr, focusGraph, focusNode, scope) -> [expr]

Node Expressions based on Blank Nodes

Named Parameter Functions

A named parameter function is a node expression function that is represented by a blank node that is the subject of at least one triple where the predicate can be used to uniquely identify the function, which is known as the key parameter.

The evaluation of a named parameter function can produce any of the following:

zero output nodes, i.e., an empty list
one or more output nodes, i.e., a list of one or more nodes
an evaluation failure, i.e., an (unexpected) error during the evaluation

For example, the named parameter function shnex:FilterShapeExpression has shnex:filterShape as its key parameter. In this document, key parameters are marked in bold face.

Expressions based on named parameter functions often take other node expressions as arguments, evaluate those input node expressions, and then produce a different list of nodes as output nodes.

The remainder of this section is informative.

This document includes many examples of named parameter functions, such as the Estonian Company Shape example.

List Parameter Functions

A list parameter function is a node expression function that is represented by a blank node that is the subject of a single triple where the object is a SHACL list. The predicate of this triple is called the list parameter property.

The evaluation of a list parameter function can produce any of the following:

one output node, i.e., a list of one node
zero output nodes, i.e., an empty list
an evaluation failure, i.e., an (unexpected) error during the evaluation

Furthermore, each argument of a list parameter function must evaluate to an individual, single node, not to a list of nodes. If an argument is a node expression, then this node expression must evaluate to a maximum of one output node. An evaluation failure must be produced if there is more than one output node. This is different from named parameter functions, where arguments may produce lists of multiple nodes.

The remainder of this section is informative.

Note that some named parameter functions — such as shnex:IntersectionExpression — also use a SHACL list as an object of the key parameter, similar to list parameter functions which always have a SHACL list as the object of their list parameter property. However, these may produce more than one output nodes, and also accept lists as input nodes.

The following example uses multiple (imaginary) list parameter functions — ex:coalesce and ex:concat — to compute the ex:displayName of a person as either the value of ex:fullName or (if that doesn't exist) as a concatenation of ex:firstName, a space, and ex:lastName.

Handling of Failures

Node expressions may produce a failure instead of a list of output nodes. Some node expressions evaluate other, nested node expressions. For example, If Expressions evaluate nested expressions for shnex:if, shnex:then and shnex:else. In general, if any such nested expressions produce a failure then the surrounding expression also produces the same failure.

The remainder of this section is informative.

Note that this policy impacts the evaluation order of node expressions. For example, shnex:if expressions are evaluated first and shnex:then will be evaluated only if the shnex:if has returned ( true ). Even if the shnex:else branch would produce a failure, the output would still only be the output nodes of the shnex:then branch.

Node Expressions Library

This section defines all node expression functions that are built into SHACL engines that implement this specification.

The syntax definitions of node expression functions that are based on blank nodes typically use a table of properties that these blank nodes can or must have. Such blank nodes are only well-formed when they are not the subject of any other triples, and when none of these properties is used more than once. The tables may also list SHACL constraints with which the property values are required to conform. In the tables, mandatory properties are rendered in bold face.

Basic Node Expressions

Var Expressions

A blank node that is the subject of the following properties is called a var expression with the function name shnex:VarExpression:

Property	Constraints	Description
`shnex:var`	`sh:datatype xsd:string` `sh:minLength 1`	The variable name, e.g. `"focusNode"`.

EVALUATION OF VAR EXPRESSIONS

Let var be the value of shnex:var in the var expression. The output nodes of the var expression are computed as follows, in order:

if var is "focusNode" then evalExpr(expr, focusGraph, focusNode, scope) -> [focusNode]
if var is in the scope then evalExpr(expr, focusGraph, focusNode, scope) -> [ scope[var] ]
otherwise evalExpr(expr, focusGraph, focusNode, scope) -> []

The remainder of this section is informative.

The following example illustrates the use of a var expression pointing at the current focus node to state that the default value of the ex:loves relationship is the current instance of ex:Person, creating a self-reference.

List Expressions

A blank node that is the subject of the following properties is called a list expression with the function name shnex:ListExpression:

Property	Constraints	Description
`rdf:first`		The first member of the list.
`rdf:rest`	Must be a well-formed SHACL list.	The rest of the list, e.g. `rdf:nil`.

EVALUATION OF LIST EXPRESSIONS

The output nodes of a list expression are the members of the SHACL list.

The remainder of this section is informative.

Note that rdf:nil itself is not a list expression because it will be interpreted as a IRI expression. As a result, all well-formed list expressions have at least one member.

The following example declares a property for instances of rdfs:Class where the values are derived from the values of the path rdfs:subClassOf* but with the constants from the list ( owl:Thing rdfs:Resource ) removed using shnex:minus.

Path Expressions

A blank node that is the subject of the following properties is called a path expression with the function name shnex:PathExpression:

Property	Constraints	Description
`shnex:path`	Must be a well-formed SHACL property path.	The path to get the values from.
`shnex:nodes`	Optional, must be a well-formed node expression.	A node expression producing the focus nodes, defaulting to the current focus node from the evaluation context.

EVALUATION OF PATH EXPRESSIONS

Let path be the value of shnex:path, and nodes be the value of shnex:nodes in the path expression. If shnex:nodes is not given, nodes is the list consistent of exactly the focus node. Let N be the nodes produced by evalExpr(nodes, focusGraph, focusNode, scope). The output nodes of the path expression are the list of nodes produced by concatenating the value nodes of the path at each node in N. TODO: Clarify if those can contain duplicates.

The remainder of this section is informative.

The following example illustrates the use of a path expression to compute the value of the property ex:topConceptCount. The path expression returns the values of skos:hasTopConcept at each skos:ConceptScheme and these are processed by the shnex:count to return the number of top concepts.

TODO: Add second example that uses shnex:nodes

Exists Expressions

A blank node that is the subject of the following properties is called an exists expression with the function name shnex:ExistsExpression:

Property	Constraints	Description
`shnex:exists`	A well-formed node expression.	A node expression. If this evaluates to a list with at least one member then the output nodes are `( true )`; otherwise, the output nodes are `( false )`.

EVALUATION OF EXISTS EXPRESSIONS

Let exists be the value of shnex:exists in the exists expression. Let N be the list of nodes produced by evalExpr(exists, focusGraph, focusNode, scope). The output nodes of the exists expression are ( true ) if and only if N has at least one member; otherwise, the output nodes are ( false ).

The remainder of this section is informative.

The Example for shnex:if uses shnex:exists.

If Expressions

A blank node that is the subject of the following properties is called an if expression with the function name shnex:IfExpression:

Property	Constraints	Description
`shnex:if`	A well-formed node expression.	A node expression. The `shnex:then` branch is returned when the `shnex:if` expression returns `true` as its only output node, in all other cases `shnex:else`.
`shnex:then`	A well-formed node expression. Optional but at least one of `shnex:then` or `shnex:else` is required.	The node expression that is returned when the `shnex:if` evaluated to `[true]`.
`shnex:else`	A well-formed node expression. Optional but at least one of `shnex:then` or `shnex:else` is required.	The node expression that is returned when the `shnex:if` did not evaluate to `[true]`.

EVALUATION OF IF EXPRESSIONS

Let if be the value of shnex:if, then be the value of shnex:then, and else be the value of shnex:else for the if expression. Let IFs be the nodes produced by evalExpr(if, focusGraph, focusNode, scope). If IFs is the list ( true ), then the output nodes of the if expression are the nodes produced by evalExpr(then, focusGraph, focusNode, scope), or the empty list if then has no value. Otherwise, the output nodes are the nodes produced by evalExpr(else, focusGraph, focusNode, scope), or the empty list if else has no value. Implementations MUST apply lazy evaluation techniques, so the shnex:then or shnex:else branches are only evaluated when necessary.

The remainder of this section is informative.

The following example illustrates the use of shnex:if to compute the values of a derived property ex:fillColor that may be queried to compute the colors of cities on a map. In the example, instances of ex:City that have a value for ex:capitalOf will be displayed in "blue", while the others will be "red".

List Operator Expressions

Distinct Expressions

A blank node that is the subject of the following properties is called a distinct expression with the function name shnex:DistinctExpression:

Property	Constraints	Description
`shnex:distinct`	A well-formed node expression.	The node expression that shall be reduced to its distinct members.

EVALUATION OF DISTINCT EXPRESSIONS

Let distinct be the value of shnex:distinct in the distinct expression. Let input be the output nodes of evalExpr(distinct, focusGraph, focusNode, scope). The output nodes of the distinct expression are the list of nodes in input in the same order but with duplicates eliminated (the first occurences of each node shall be kept, the others removed). Nodes are compared using term equality, i.e. "01"^^xsd:integer is distinct from "1"^^xsd:integer.

The remainder of this section is informative.

The following example declares a derived property ex:superClassesIncludingRoot that is computed as the union of the (transitive) values of rdfs:subClassOf and the list expression ( rdfs:Resource ). Since the asserted values of rdfs:subClassOf may already include rdfs:Resource (for example, due to an active inference engine on the data graph), shnex:distinct will make sure that the output nodes do not include rdfs:Resource twice.

Intersection Expressions

A blank node that is the subject of the following properties is called an intersection expression with the function name shnex:IntersectionExpression:

Property	Constraints	Description
`shnex:intersection`	A well-formed SHACL list where each member is a well-formed node expression.	The node expressions that shall be intersected.

EVALUATION OF INTERSECTION EXPRESSIONS

Let members be the members of the value of shnex:intersection in the intersection expression. The output nodes of the intersection expression are the nodes that form the intersection of the output nodes produced by each node expression NE in members, using evalExpr(NE, focusGraph, focusNode, scope). Nodes must be equal using term equality, i.e. "01"^^xsd:integer is distinct from "1"^^xsd:integer.

The remainder of this section is informative.

The following example uses shnex:intersection as a sh:targetNode node expression. This shape will target all nodes that are SHACL instances of ex:Australian and ex:German at the same time.

Union Expressions

A blank node that is the subject of the following properties is called a union expression with the function name shnex:UnionExpression:

Property	Constraints	Description
`shnex:union`	A well-formed SHACL list where each member is a well-formed node expression.	The node expressions that shall be unioned.

EVALUATION OF UNION EXPRESSIONS

Let members be the members of the value of shnex:union in the union expression. The output nodes of the union expression are the concatenation of all output nodes for each node expression NE in members, using evalExpr(NE, focusGraph, focusNode, scope). The order is preserved, evaluating the members from left to right and keeping the order of each list of output nodes.

The remainder of this section is informative.

Note that a union expression may produce duplicate output nodes if the individual output nodes overlap. Use shnex:distinct to eliminate duplicates.

The Example for shnex:distinct uses shnex:union.

Minus Expressions

A blank node that is the subject of the following properties is called a minus expression with the function name shnex:MinusExpression:

Property	Constraints	Description
`shnex:minus`	A well-formed node expression.	The nodes that shall be removed from the `shnex:nodes`.
`shnex:nodes`	A well-formed node expression.	The input nodes.

EVALUATION OF MINUS EXPRESSIONS

Let minus be the value of shnex:minus and nodes be the value of shnex:nodes in the minus expression. Let M be the output nodes of evalExpr(minus, focusGraph, focusNode, scope). Let N be the output nodes of evalExpr(nodes, focusGraph, focusNode, scope). The output nodes of the minus expression are the nodes in N except those that are also in M, preserving the order of N. Nodes must be equal using term equality, i.e. "01"^^xsd:integer is distinct from "1"^^xsd:integer.

The remainder of this section is informative.

The List Expression example uses shnex:minus.

FilterShape Expressions

A blank node that is the subject of the following properties is called a filterShape expression with the function name shnex:FilterShapeExpression:

Property	Constraints	Description
`shnex:filterShape`	A well-formed shape.	The shape that all input nodes need to conform to.
`shnex:nodes`	A well-formed node expression.	A node expression producing the nodes that are validated.

EVALUATION OF FILTERSHAPE EXPRESSIONS

Let filterShape be the value of shnex:filterShape, and nodes be the value of shnex:nodes in a filterShape expression. The output nodes of the filterShape expression are the output nodes of evalExpr(nodes, focusGraph, focusNode, scope) except those that do not conform to the shape filterShape, preserving the order in the list.

The remainder of this section is informative.

The following example illustrates the use of shnex:filterShape to return a subset of values of the ex:child property where the ex:gender property has the value "male".

Limit Expressions

A blank node that is the subject of the following properties is called a limit expression with the function name shnex:LimitExpression:

Property	Constraints	Description
`shnex:limit`	`sh:datatype xsd:integer` `sh:minInclusive 0`	The maximum number of nodes that shall be returned.
`shnex:nodes`	A well-formed node expression.	The input nodes.

EVALUATION OF LIMIT EXPRESSIONS

Let limit be the value of shnex:limit and nodes be the value of shnex:nodes in the limit expression. Let N be the output nodes of evalExpr(nodes, focusGraph, focusNode, scope). The output nodes of the limit expression are the first limit nodes in N from left to right, in the same order.

The remainder of this section is informative.

The following example illustrates the use of shnex:limit to compute the values of a derived property ex:oldestChildren to be a sub-list of values of ex:child at the current focus node (which is an instance of the class ex:Person). The values are computed by first fetching the values of ex:child, then ordering them by their ex:dateOfBirth, and finally getting only 2 of these children at most.

Offset Expressions

A blank node that is the subject of the following properties is called an offset expression with the function name shnex:OffsetExpression:

Property	Constraints	Description
`shnex:offset`	`sh:datatype xsd:integer` `sh:minInclusive 0`	The number of nodes that shall be skipped from the `shnex:nodes`.
`shnex:nodes`	A well-formed node expression.	The input nodes.

EVALUATION OF OFFSET EXPRESSIONS

Let offset be the value of shnex:offset and nodes be the value of shnex:nodes in the offset expression. Let N be the output nodes of evalExpr(nodes, focusGraph, focusNode, scope). The output nodes of the offset expression are the nodes in N except for the first offset nodes from left to right, in the same order.

The remainder of this section is informative.

The following example illustrates the use of shnex:offset to compute the values of a derived property ex:remainingChildren to be a sub-list of values of ex:child at the current focus node (which is an instance of the class ex:Person). The values are computed by first fetching the values of ex:child, then ordering them by their ex:dateOfBirth, and finally skipping the first of these children.

OrderBy Expressions

TODO: This should be cleaned up from the SHACL-AF definition and requires thought

The Example of shnex:limit also illustrates shnex:orderBy.

Aggregation Expressions

Count Expressions

A blank node that is the subject of the following properties is called a count expression with the function name shnex:CountExpression:

Property	Constraints	Description
`shnex:count`	A well-formed node expression.	The input nodes that shall be counted.

EVALUATION OF COUNT EXPRESSIONS

Let count be the value of shnex:count in the count expression. Let N be the output nodes of evalExpr(count, focusGraph, focusNode, scope). The output nodes of the count expression is the list consisting of exactly one xsd:integer literal that is computed as the length of N.

The remainder of this section is informative.

The following example illustrates the use of shnex:count to derive a property ex:topConceptCount as the number of values of the skos:hasTopConcept property in a skos:ConceptScheme.

Min Expressions

A blank node that is the subject of the following properties is called a min expression with the function name shnex:MinExpression:

Property	Constraints	Description
`shnex:min`	A well-formed node expression.	The input nodes from which the minimum value shall be returned.

EVALUATION OF MIN EXPRESSIONS

Let min be the value of shnex:min in the min expression. Let N be the output nodes of evalExpr(min, focusGraph, focusNode, scope). The output nodes of the min expression is the list consisting of at most one node that is computed as the minimum value from N. Clarify exactly how that is computed, maybe via reference to SPARQL MIN

The remainder of this section is informative.

The following example illustrates the use of shnex:min to derive a property ex:minStartDate as the smallest value of the values that can be reached using the property path ex:exployee/ex:startDate. In other words, it walks through all employees of the given company and returns the earliest date on which an employee started.

Max Expressions

A blank node that is the subject of the following properties is called a max expression with the function name shnex:MaxExpression:

Property	Constraints	Description
`shnex:max`	A well-formed node expression.	The input nodes from which the maximum value shall be returned.

EVALUATION OF MAX EXPRESSIONS

Let max be the value of shnex:max in the max expression. Let N be the output nodes of evalExpr(max, focusGraph, focusNode, scope). The output nodes of the max expression is the list consisting of at most one node that is computed as the maximum value from N. Clarify exactly how that is computed, maybe via reference to SPARQL MAX

The remainder of this section is informative.

The Example for shnex:min can be easily adapted for shnex:max.

Sum Expressions

A blank node that is the subject of the following properties is called a sum expression with the function name shnex:SumExpression:

Property	Constraints	Description
`shnex:sum`	A well-formed node expression.	The input nodes from which the sum shall be returned.

EVALUATION OF SUM EXPRESSIONS

Let sum be the value of shnex:sum in the sum expression. Let N be the output nodes of evalExpr(sum, focusGraph, focusNode, scope). The output nodes of the sum expression is the list consisting of exactly one node that is computed as the sum of all nodes from N. Clarify exactly how that is computed, maybe via reference to SPARQL SUM

The remainder of this section is informative.

Note that shnex:sum needs to be used with care and may be often misunderstood, when used with property paths. The problem is that when a path expression is used as input to a sum expression, the path expression will have eliminated duplicates before they can be processed by the shnex:sum. As a result, only the distinct values will be added up.

TODO: Find good example, or drop the feature if none makes sense

Miscellaneous Node Expressions

This section enumerates node expression functions that did not fit into other categories.

InstancesOf Expressions

A blank node that is the subject of the following properties is called an instancesOf expression with the function name shnex:InstancesOfExpression:

Property	Constraints	Description
`shnex:instancesOf`	`sh:nodeKind sh:IRI`	The class that the output nodes must be instances of.

EVALUATION OF INSTANCESOF EXPRESSIONS

Let type be the value of shnex:instancesOf in an instancesOf expression. The output nodes of the instancesOf expression are the nodes that are SHACL instances of type in the focus graph.

The remainder of this section is informative.

Note that the definition of SHACL instance includes instances of subclasses of the given class. So if the focus graph contains ex:SubClass rdfs:subClassOf ex:SuperClass and ex:SubInstance a ex:SubClass then ex:SubInstance will also be returned as instance of ex:SuperClass.

The interpretation of shnex:instancesOf is similar to sh:targetClass and sh:class.

Users of this node expression function should be aware that the list of output nodes may be very large.

The Example for shnex:intersection uses shnex:instanceOf.

Constraint Components

This section introduces SHACL constraint components that operate on node expressions.

sh:expression

Based on node expressions, this section introduces a constraint component called expression constraints. Expression constraints can be used in any shape to declare the condition that the node expression specified via sh:expression has true as its only output node. The evaluation of these node expressions is repeated for all value nodes of the shape as the focus node.

Constraint Component IRI: sh:ExpressionConstraintComponent

Parameters:

Property	Summary and Syntax Rules
`sh:expression`	The node expression that must return `true`. The values of `sh:expression` at a shape must be well-formed node expressions.

TEXTUAL DEFINITION

Let $expr be a value of sh:expression. For each value node v where evalExpr(expr, data graph, focusNode, {value: v}) does not return the list consisting of exactly true as its output nodes, there is a validation result that has v as its sh:value and a deep copy of $expr in the results graph as its sh:sourceConstraint.

The remainder of this section is informative.

Note that the scope in the evaluation of expression constraints contains the variable value for the current value node while the variable focusNode is the focus node.

The following example uses some SPARQL-based node expressions to declare the constraint that the values of ex:ibanNumber must start with the same two (upper-case) letters as the values of the path ex:country/ex:code.

sh:nodeByExpression

sh:nodeByExpression specifies the condition that each value node conforms to the node shapes produced by a node expression. The evaluation of these node expressions is repeated for all value nodes of the shape as the focus node.

Constraint Component IRI: sh:NodeByExpressionConstraintComponent

Parameters:

Property	Summary and Syntax Rules
`sh:nodeByExpression`	The node shapes that all value nodes need to conform to. The values of `sh:nodeByExpression` in a shape must be well-formed node expressions.

TEXTUAL DEFINITION

Let $expr be a value of sh:nodeByExpression. For each value node v: perform a conformance check of v against each output node of

evalExpr(expr,
						data graph, v, {})

s. A failure MUST be produced if the conformance check of v against s produces a failure. Otherwise, if v does not conform to s, there is a validation result with v as sh:value and a deep copy of s as sh:sourceConstraint.

The remainder of this section is informative.

sh:nodeByExpression functions similarly to sh:node, but instead of referencing a fixed node shape, a referenced node expression is used to dynamically compute the set of node shapes to which each value node must conform.

There are three key differences between sh:nodeByExpression and sh:node:

sh:nodeByExpression references a node expression instead of a fixed node shape as sh:node does.
sh:nodeByExpression cannot reference a node shape that is a blank node as a value like sh:node can, as a blank node would be interpreted as a node expression.
Results generated by sh:nodeByExpression additionally include a value for `sh:sourceConstraint`.

Note that sh:node and sh:nodeByExpression exhibit the same behavior when given a value that is an IRI of a node shape. In this case, sh:node directly validates against the specified node shape, whereas sh:nodeByExpression interprets the IRI as an IRI expression that evaluates to a set containing the same node shape.

The following example demonstrates how sh:nodeByExpression could be used in the context of the W3C Data Cube Vocabulary. Building upon examples 5 and 6 from the Data Cube Vocabulary documentation, Data Structure Definition is extended with the property eg:hasShape, which links to an associated node shape to which relevant qb:Observation instances must conform. To validate that every qb:Observation instance conforms to the appropriate shape, sh:nodeByExpression with a Path Expression is used to locate the shape at the property path qb:dataSet/qb:structure/eg:hasShape from each qb:Observation instance.

eg:dsd1-shape a sh:NodeShape ; sh:property [ # _:b1 sh:path sdmx-dimension:refTime ; sh:datatype xsd:date ; sh:minCount 1 ; sh:maxCount 1 ; ] ; sh:property [ # _:b2 sh:path eg-measure:quantity ; sh:datatype xsd:integer ; sh:minCount 1 ; sh:maxCount 1 ; sh:minInclusive 0 ; ] ; sh:property [ # _:b3 sh:path eg-measure:weight ; sh:datatype xsd:decimal ; sh:minCount 1 ; sh:maxCount 1 ; sh:minInclusive 0.0 ; ] . eg:ObservationShape a sh:NodeShape ; sh:targetClass qb:Observation ; sh:nodeByExpression [ shnex:path (qb:dataSet qb:structure eg:hasShape) ; ] .

{
	"@graph": [
		{
			"@id": "eg:dsd1-shape",
			"@type": "sh:NodeShape",
			"sh:property": [
				{
					"@id": "_:b1",
					"sh:path": {
						"@id": "sdmx-dimension:refTime"
					},
					"sh:datatype": {
						"@id": "xsd:date"
					},
					"sh:minCount": {
						"@type": "xsd:integer",
						"@value": "1"
					},
					"sh:maxCount": {
						"@type": "xsd:integer",
						"@value": "1"
					}
				},
				{
					"@id": "_:b2",
					"sh:path": {
						"@id": "eg-measure:quantity"
					},
					"sh:datatype": {
						"@id": "xsd:integer"
					},
					"sh:minCount": {
						"@type": "xsd:integer",
						"@value": "1"
					},
					"sh:maxCount": {
						"@type": "xsd:integer",
						"@value": "1"
					},
					"sh:minInclusive": {
						"@type": "xsd:integer",
						"@value": "0"
					}
				},
				{
					"@id": "_:b3",
					"sh:path": {
						"@id": "eg-measure:weight"
					},
					"sh:datatype": {
						"@id": "xsd:decimal"
					},
					"sh:minCount": {
						"@type": "xsd:integer",
						"@value": "1"
					},
					"sh:maxCount": {
						"@type": "xsd:integer",
						"@value": "1"
					},
					"sh:minInclusive": {
						"@type": "xsd:decimal",
						"@value": "0.0"
					}
				}
			]
		},
		{
			"@id": "eg:ObservationShape",
			"@type": "sh:NodeShape",
			"sh:targetClass": {
				"@id": "qb:Observation"
			},
			"sh:nodeByExpression": {
				"shnex:path": {
					"@list": [
						{
							"@id": "qb:dataSet"
						},
						{
							"@id": "qb:structure"
						},
						{
							"@id": "eg:hasShape"
						}
					]
				}
			}
		}
	]
}

eg:dataset1 a qb:DataSet ; qb:structure eg:dsd1 . eg:dsd1 a qb:DataStructureDefinition ; rdfs:comment "shipments by time (multiple measures approach)"@en ; eg:hasShape eg:dsd1-shape ; qb:component [ qb:dimension sdmx-dimension:refTime; ] ; qb:component [ qb:measure eg-measure:quantity ; ] ; qb:component [ qb:measure eg-measure:weight ; ] . eg:obs1a a qb:Observation; qb:dataSet eg:dataset1; sdmx-dimension:refTime "2010-07-30"^^xsd:date; eg-measure:weight 1.3 ; eg-measure:quantity 42 . eg:obs1b a qb:Observation; qb:dataSet eg:dataset1; sdmx-dimension:refTime "2010-07-31T12:00:00"^^xsd:dateTime; eg-measure:weight 1.4 .

{
	"@graph": [
		{
			"@id": "eg:dataset1",
			"@type": "qb:DataSet",
			"qb:structure": {
				"@id": "eg:dsd1"
			}
		},
		{
			"@id": "eg:dsd1",
			"@type": "qb:DataStructureDefinition",
			"rdfs:comment": {
				"@language": "en",
				"@value": "shipments by time (multiple measures approach)"
			}
			"eg:hasShape": {
				"@id": "eg:dsd1-shape"
			},
			"qb:component": [
				{
					"qb:dimension": {
						"@id": "sdmx-dimension:refTime"
					}
				},
				{
					"qb:measure": {
						"@id": "eg-measure:quantity"
					}
				},
				{
					"qb:measure": {
						"@id": "eg-measure:weight"
					}
				}
			]
		},
		{
			"@id": "eg:obs1a",
			"@type": "qb:Observation",
			"qb:dataSet": {
				"@id": "eg:dataset1"
			},
			"sdmx-dimension:refTime": {
				"@type": "xsd:date",
				"@value": "2010-07-30"
			},
			"eg-measure:quantity": {
				"@type": "xsd:integer",
				"@value": "42"
			},
			"eg-measure:weight": {
				"@type": "xsd:decimal",
				"@value": "1.3"
			}
		},
		{
			"@id": "eg:obs1b",
			"@type": "qb:Observation",
			"qb:dataSet": {
				"@id": "eg:dataset1"
			},
			"sdmx-dimension:refTime": {
				"@type": "xsd:dateTime",
				"@value": "2010-07-31T12:00:00"
			}
			"eg-measure:weight": {
				"@type": "xsd:decimal",
				"@value": "1.4"
			},
		}
	]
}

[ a sh:ValidationReport ; sh:conforms false ; sh:result [ a sh:ValidationResult ; sh:resultSeverity sh:Violation ; sh:focusNode eg:obs1b; sh:value eg:obs1b ; sh:resultMessage "Value does not conform to shape eg:dsd1-shape." ; sh:sourceConstraint eg:dsd1-shape ; sh:sourceConstraintComponent sh:NodeByExpressionConstraintComponent ; sh:sourceShape eg:ObservationShape ; sh:detail [ a sh:ValidationResult ; sh:resultSeverity sh:Violation ; sh:focusNode eg:obs1b ; sh:resultPath sdmx-dimension:refTime ; sh:value "2010-07-31T12:00:00"^^xsd:dateTime ; sh:resultMessage "Value does not have datatype xsd:date" ; sh:sourceConstraintComponent sh:DatatypeConstraintComponent ; sh:sourceShape _:b1 ; ] ; sh:detail [ a sh:ValidationResult ; sh:resultSeverity sh:Violation ; sh:focusNode eg:obs1b ; sh:resultPath eg-measure:quantity ; sh:resultMessage "Less than 1 values" ; sh:sourceConstraintComponent sh:MinCountConstraintComponent ; sh:sourceShape _:b2 ; ] ; ] ; ] .

{
	"@type": "sh:ValidationReport",
	"sh:conforms": {
		"@type": "xsd:boolean",
		"@value": "false"
	},
	"sh:result": {
		"@type": "sh:ValidationResult",
		"sh:resultSeverity": {
			"@id": "sh:Violation"
		},
		"sh:focusNode": {
			"@id": "eg:obs1b"
		},
		"sh:value": {
			"@id": "eg:obs1b"
		},
		"sh:resultMessage": "Value does not conform to shape eg:dsd1-shape.",
		"sh:sourceConstraint": {
			"@id": "eg:dsd1-shape"
		},
		"sh:sourceConstraintComponent": {
			"@id": "sh:NodeByExpressionConstraintComponent"
		},
		"sh:sourceShape": {
			"@id": "eg:ObservationShape"
		},
		"sh:detail": [
			{
				"@type": "sh:ValidationResult",
				"sh:resultSeverity": {
					"@id": "sh:Violation"
				},
				"sh:focusNode": {
					"@id": "eg:obs1b"
				},
				"sh:resultPath": {
					"@id": "sdmx-dimension:refTime"
				},
				"sh:value": {
					"@type": "xsd:dateTime",
					"@value": "2010-07-31T12:00:00"
				},
				"sh:resultMessage": "Value does not have datatype xsd:date",
				"sh:sourceConstraintComponent": {
					"@id": "sh:DatatypeConstraintComponent"
				},
				"sh:sourceShape": {
					"@id": "_:b1"
				}
			},
			{
				"@type": "sh:ValidationResult",
				"sh:resultSeverity": {
					"@id": "sh:Violation"
				},
				"sh:focusNode": {
					"@id": "eg:obs1b"
				},
				"sh:resultPath": {
					"@id": "eg-measure:quantity"
				},
				"sh:resultMessage": "Less than 1 values",
				"sh:sourceConstraintComponent": {
					"@id": "sh:MinCountConstraintComponent"
				},
				"sh:sourceShape": {
					"@id": "_:b2"
				}
			}
		]
	}
}

Security Considerations

TODO

Privacy Considerations

TODO

Internationalization Considerations

TODO

Introduction

Terminology

Document Conventions

Getting started with Node Expressions

Node Expression Syntax

Constant Node Expressions

IRI Expressions

Literal Expressions

Node Expressions based on Blank Nodes

Named Parameter Functions

List Parameter Functions

Handling of Failures

Node Expressions Library

Basic Node Expressions

Var Expressions

List Expressions

Path Expressions

Exists Expressions

If Expressions

List Operator Expressions

Distinct Expressions

Intersection Expressions

Union Expressions

Minus Expressions

FilterShape Expressions

Limit Expressions

Offset Expressions

OrderBy Expressions

Aggregation Expressions

Count Expressions

Min Expressions

Max Expressions

Sum Expressions

Miscellaneous Node Expressions

InstancesOf Expressions

Constraint Components

sh:expression

sh:nodeByExpression

Security Considerations

Privacy Considerations

Acknowledgements

Internationalization Considerations
